150W Voltage/Current

  • 1750mA 42-84VDC IP65 moisture-proof drivers for bathroom lights
  • 1750mA 42-84VDC IP65 moisture-proof drivers for bathroom lights
  • 1750mA 42-84VDC IP65 moisture-proof drivers for bathroom lights
  • 1750mA 42-84VDC IP65 moisture-proof drivers for bathroom lights
1750mA 42-84VDC IP65 moisture-proof drivers for bathroom lights1750mA 42-84VDC IP65 moisture-proof drivers for bathroom lights1750mA 42-84VDC IP65 moisture-proof drivers for bathroom lights1750mA 42-84VDC IP65 moisture-proof drivers for bathroom lights

1750mA 42-84VDC IP65 moisture-proof drivers for bathroom lights

  • Model Number: APVM-150C-1750
  • 1750mA 150W Waterproof LED Driver
  • 1750mA led Strip Current driver
  • 150W 1750mA 42-84VDC
  • Product description: 150W 1750mA 42-84VDC IP67 Waterproof LED Current Driver for led strips, led panel lights, spotlights, sky panel lights, led modules, illuminated lightbox
  • INQUIRY


AC-DC Single output LED driver Constant Current (CC),Output 1750mA at 42-84Vdc 150W Full Power


APVM-150C series is highly competitive in the cost planning of system design. Work efficiency up to 93%, IP67 waterproof grade, to prevent dust and moisture. It is suitable for various kinds of constant current LED lighting related to decorative lighting, architectural lighting, wall lamp and advertising field.
Output 150W 1750mA 42-84VDC.

Constant Current output

high wattage drivers for outdoor and high lumen applications feature thermal protection circuits with a variety of control options.

applications are ideal for high lumen downlights, high bay fixtures, and outdoor luminaire applications.

wattage drivers are designed to meet your linear, track, and downlight needs.


Product Features:


1. Constant current mode

2. 180~264VAC input only

3. High efficiency up to 92%

4. Fully encapsulated with IP67 level

5. Isolation class II, no F.G.

6. Class 2 power unit

7.Low cost, high reliability

8. Suitable for LED-based decorative / architectural lighting,LED stage, theater lighting, and LED electronic displays

9. Protections: Short circuit / Over voltage / Over temperature/Overload

10. 3 years warranty

Model Number: APVM-150C-1750

Constant Current LED Drivers

Input: 200-240VAC, 47-63HZ, 1.5A

Output current: 1750mA

Output Voltage: 42-84VDC

Output Power:150W Max

Working efficiency>92%

Inrush Current: 60A Max at 230VAC 50Hz,full load

Protection: OverVoltage/OverLoad/Short circuit/Over temperature

IP Rating: Fully encapsulated with IP67 level

Working temperature range: -40°C to 70°C

Working humidity: 10%-90%RH Non-condensing

Electronic Connection: 300mm VDE certified Cables

AC input cable: 2x1.0mm2  BLue/Brow

DC output Cable: 2x1.5mm2  Black/RED

Number of output: 1 channel

Compliance with CE EMC LVD ROHS SELV LPS
Dimension: 191x52x37mm,
Packing: 0.63Kg;20pcs/13.6Kg/0.03CBM

Suitable for LED related fixture or appliance (such as LED Decoration or Advertisement devices, illuminated signs, lightbox, linear lighting)


Other Output Current Options available:


Model NO

Input Voltage

Output Voltage

Output current

Output Power

Efficiency

Dimension/mm

APVM-150-700

200-277VAC

107-214VDC

700mA

150W

92%

191x52x37

APVM-150-1050

200-277VAC

72-144VDC

1050mA

150W

92%

191x52x37

APVM-150-1400

200-277VAC

54-107VDC

1400mA

150W

92%

191x52x37

APVM-150-1750

200-277VAC

42-84VDC

1750mA

147W

92%

191x52x37

APVM-150-2100

200-277VAC

36-72VDC

2100mA

150W

92%

191x52x37

APVM-150-2800

200-277VAC

27-54VDC

2800mA

150W

92%

191x52x37

APVM-150-3500

200-277VAC

21-42VDC

3500mA

147W

92%

191x52x37

APVM-150-5000

200-277VAC

15-30VDC

5000mA

150W

92%

191x52x37
