Product Features:
1.176-305VAC wide input voltage range
2.Constant voltage + Constant Current Drive Mode
3.Built in active PF function, PF>0,95
4.High working efficiency up to 92%
5.THD<15%, Flicker-Free Design
6.IP67 waterproof level with fine aluminum housing, suitable for outdoor applications
7.Flicker-Free,Low ripple
8.4KV + 6KV Surge protection, more safety
9. 100% Constant Power
10. 5 years warranty
Technical Specification:
Model |
APMS-200-24 |
Remarks |
||
Output |
Rated Output voltage |
24 |
VDC |
|
Rated Output Current |
8.3 |
A |
||
Rated Output Power |
200 |
W |
||
Efficiency |
≥90% (Typical 91%) |
200VAC input, Rated Load |
||
≥91% (Typical 92%) |
240VAC input, Rated Load |
|||
Line Regulation |
±0.5% |
|||
Load Regulation |
±1.5% |
|||
Voltage tolerance |
±2% |
|||
Ripple & Noise (max) |
≤240 |
mVp-p |
Measured at 20MHZ of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47 uf parallel capacitor |
|
Rise time |
≤60 |
mS |
25℃ , full load |
|
Power On Delay time |
≤3 |
S |
200-240VAC, full load |
|
Switch off Hold Up time |
/ |
ms |
Rated input voltage, rated load |
Model |
APMS-200-24 |
Remarks |
||
Input |
Rated Input voltage |
200-277 |
VAC |
|
Input voltage range |
176-305 |
VAC |
||
Input Frequency |
47-63(Typical 50/60) |
Hz |
||
Input Current Max |
1.5 |
A |
Vin=176Vac, Full Load |
|
Inrush Current |
≤70 |
A |
220Vac, full load, 25℃ |
|
Power Factor |
≥0.95 |
176~277Vac input, full load |
||
THD |
≤15 |
% |
Vin=176~277Vac, full load |
|
Protection |
Current Limiting |
112%-144% of rated output current |
Hi-CCUP Mode, Auto-recovery after fault condition is removed |
|
Over Voltage |
27±1 |
V |
Shut down output voltage, re-power on to recover |
|
Over Temperature |
≥110 |
℃ |
Inner temperature, Auto-recovery |
|
Short circuit |
Yes |
Hi-CCUP Mode, Auto-recovery after fault condition is removed |
||
Input undervoltage |
>150 |
V |
||
Environment |
Operating Temperature range |
-40 to +80(Typical25) |
℃ |
Refer to Derating Curve |
Storage Temperature range |
-45 to +80(Typical25 |
℃ |
||
Humidity |
10~95 |
% |
NON-Condensing |
|
Altitude |
0~5000 |
M |
Altitude Over 2000 meters, 1.5% derating for every 100 meters increase |
|
Waterproof Level |
IP67 full sealed |
|||
Cooling method |
Air convection |
|||
Temperature Coefficient |
0.03%/℃ (0-60℃ ) |
|||
Vibration |
10-500Hz, 5G 12min./1cycle, period for 72 min, each along X.Y. Z axes |
|||
Safety Standards |
Safety standard |
UL8750, IEC/EN61347-1,EN61347-2-13,EN62368, GB19510.1,GB19510.14, IP67 Approved |
||
Withstand voltage |
I/P-O/P |
3000Vac 10mA (Max) |
||
I/P-FG |
1500Vac 10mA (Max) |
|||
O/P-FG |
500Vac 10mA (Max) |
|||
Isolation Resistance |
I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25℃/ 70% RH |
|||
Leakage Current |
<0.75mA |
240Vac/60Hz |
EMI |
Conducted |
EN55015(CISPR15), GB17743 |
Radiated |
EN55015(CISPR15), GB17743 |
|
Harmonic Current |
EN61000-3-2 , Class C @load≥50% |
|
EMS |
ESD |
EN61000-4-2, 8KV air ; Level 2, 4KV contact |
Radiated |
EN61000-4-3 |
|
EFT/Burst |
EN61000-4-4 |
|
Surge |
EN61000-4-5,4KV/Line-Line 6KV/Line-Earth |
|
Conducted |
EN61000-4-6 |
|
EN61547, Electromagnetic Immunity Requirements applies to lighting Equipment |
||
Others |
MTBF |
>200Khours, MIL-HDBK-217F (25℃) |
Dimension |
199(L)*63 (W)*40(H) mm |
|
Packing |
0.85Kg;16pcs /14.2Kg/0.026CBM |
