100W Voltage/Current

  • 100W 700mA 72-144VDC IP67 Waterproof LED Current Drivers Plastic
  • 100W 700mA 72-144VDC IP67 Waterproof LED Current Drivers Plastic
  • 100W 700mA 72-144VDC IP67 Waterproof LED Current Drivers Plastic
100W 700mA 72-144VDC IP67 Waterproof LED Current Drivers Plastic100W 700mA 72-144VDC IP67 Waterproof LED Current Drivers Plastic100W 700mA 72-144VDC IP67 Waterproof LED Current Drivers Plastic

100W 700mA 72-144VDC IP67 Waterproof LED Current Drivers Plastic

  • 100W 700mA LED Driver
  • waterproof led driver
  • led panel current driver
  • 700mA Current driver
  • Product description: 100W 700mA IP67 Waterproof LED Current Drivers Plastic housing for led strips, led modules, lightbox, cabinet lights, led panels, illuminated sky panel
  • INQUIRY

100W 700mA IP67 Water & Dust-Proof LED Power Supplies LED Driver

Constant current output with high output voltage>60VDC
Meet 4KV surge immunity level
Class Il Power unit, Double isolated, no FG


Product description
1. constant current output with high output voltage>60VDC
2. 180~264VAC input only
3. Isolated Plastic housing
4. High efficiency up to 93%
5.Protections: Short circuit / Over voltage / Over temperature/Over Load
6.Cooling by free air convection
7. Fixed Output current
8.IP67 / IP65 design for indoor or outdoor installations
9.Suitable for dry / damp / wet locations
10. Suitable for LED lighting and advertising applications
11. 3years warranty


Model Number: APVM-100C-700
Constant Current LED Driver, Isolated Flicker-free
Input voltage: 200-240VAC, 47-63HZ
Output Current: 700mA
Output voltage: 72-144VDC

Output Power:100W Max

Working efficiency>90%

IP Rating: Fully encapsulated with IP67 level
Inrush Current: 60A Max at 230VAC/50Hz, full loadWorking temperature range: -40°C to 70°C
Working humidity: 10%-90%RH Non-condensing

Electronic Connection: 300mm VDE certified Cables

AC input cable: 2x1.0mm2  BLue/Brow

DC output Cable: 2x1.5mm2  Black/RED

Number of output: 1 channel

Compliance with CE EMC LVD ROHS SELV LPS
Dimension: 163x42x34mm,
Packing: Packing: 0.4Kg; 30pcs/13.0Kg/0.0.2CBM


Suitable for LED related fixture or appliance (such as LED Decoration or Advertisement devices)



Other Output Current Options:

Model NO

Input Voltage

Output Voltage

Output current

Output Power

Efficiency

Dimension/mm

APVM-100-700

200-240VAC

72-144VDC

700mA

100W

89%

162x43x32

APVM-100-1050

200-240VAC

48-96VDC

1050mA

100W

89%

162x43x32

APVM-100-1400

200-240VAC

36-72VDC

1400mA

100W

89%

162x43x32

APVM-100-1750

200-240VAC

28-57VDC

1750mA

98W

89%

162x43x32

APVM-100-2100

200-240VAC

24-48VDC

2100mA

100W

89%

162x43x32

APVM-100-2800

200-240VAC

18-36VDC

2800mA

100W

89%

162x43x32

APVM-100-3500

200-240VAC

14-27VDC

3500mA

96W

89%

162x43x32
