Constant voltage

  • 100W 36V aluminum waterproof LED Driver
100W 36V aluminum waterproof LED Driver

100W 36V aluminum waterproof LED Driver

  • APMS-100-36
  • 36V outdoor led driver
  • signage driver
  • floodlights led driver
  • Product description: 100W 36V waterproof LED Power Supply, IP67 waterproof type, used for outdoor led lighting, floodlights, LED wall washer lights, illuminated signs, light box, linear lighting
  • INQUIRY


Product Features:

1.176-305VAC wide input voltage range

2.Constant Power 100%

3.Built in active PF function, PF>0,95

4.High working efficiency up to 90%

5.THD<15%, Flicker-Free Design

6.IP67 waterproof level with fine aluminum housing, suitable for outdoor applications

7.Class 2 Power unit

8.4KV + 6KV Surge protection, more safety

9.Constant voltage + Constant Current Drive Mode

10. 100% Constant Power

11. 5 years warranty

Technical Specification:

Model

APMS-100-36

Remarks









Output

Rated Output voltage

36

VDC

Rated Output Current

2.77

A

Rated Output Power

100

W

Efficiency

91% (Typical 92%)

200VAC input, Rated Load

92% (Typical 93%)

240VAC input, Rated Load

Line Regulation

±0.5%

Load Regulation

±1.5%

Voltage tolerance

±2%

Ripple & Noise  (max)

240

mVp-p

Measured at 20MHZ of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47 uf parallel capacitor

Rise time

60

mS

25 , full load

Power On Delay time

3

S

200-240VAC, full load

Switch off Hold Up time

/

ms

Rated input voltage, rated load

Model

APMS-100-36

Remarks





Input

Rated Input voltage

200-277

VAC

Input voltage range

176-305

VAC

Input Frequency

47-63(Typical 50/60)

Hz

Input Current Max

1.0

A

Vin=176Vac, Full Load

Inrush Current

80

A

220Vac, full load, 25℃

Power Factor

0.95

176~277Vac input, full load

THD

15

%

Vin=176~277Vac, full load





Protection

Current Limiting

112%-137% of rated output current

Hi-CCUP Mode, Auto-recovery

after fault condition is removed

Over Voltage

YES

V

Shut down output voltage, re-power on to recover

Over Temperature

110

Inner temperature, Auto-recovery

Short circuit

Yes

Hi-CCUP Mode, Auto-recovery

after fault condition is removed

Input undervoltage

>150

V







Environment

Operating Temperature range

-40 to +80Typical25

Refer to Derating Curve

Storage Temperature range

-45 to +80Typical25

Humidity

1095

%

NON-Condensing

Altitude

05000

M

Altitude Over 2000 meters, 1.5% derating for every 100 meters increase

Waterproof Level

IP67 full sealed

Cooling method

Air convection

Temperature Coefficient

0.03%/ (0-60 )

Vibration

10-500Hz, 5G 12min./1cycle, period for 72 min, each along X.Y. Z axes




Safety Standards

Safety standard

UL8750, IEC/EN61347-1,EN61347-2-13,EN62368, GB19510.1,GB19510.14, IP67 Approved

Withstand voltage

I/P-O/P

3000Vac   10mA (Max)

I/P-FG

1500Vac   10mA (Max)

O/P-FG

500Vac   10mA (Max)

Isolation Resistance

I/P-O/P, I/P-FG, O/P-FG:100M Ohms / 500VDC / 25℃/ 70% RH

Leakage Current

0.75mA

240Vac/60Hz


EMI

Conducted

EN55015(CISPR15), GB17743

Radiated

EN55015(CISPR15), GB17743

Harmonic Current

EN61000-3-2 , Class C @load≥50%



EMS

ESD

EN61000-4-2, 8KV air ; Level 2, 4KV contact

Radiated

EN61000-4-3

EFT/Burst

EN61000-4-4

Surge

EN61000-4-54KV/Line-Line 6KV/Line-Earth

Conducted

EN61000-4-6

EN61547, Electromagnetic Immunity Requirements applies to lighting Equipment


Others

MTBF

>200Khours, MIL-HDBK-217F (25℃)

Dimension

156(L)*63 (W)*40(H)

Packing

0.58Kg;24pcs /15Kg /0.026CBM
