150W 24V APF SELV IP67 Waterproof LED Module Power with PFC

LED Driver, 150W 24V Waterproof LED Driver Transformer 180-264VAC to 24V 6.25A DC Electric D Power Supply for 24V LED Products

CONSTANT OUTPUT LED DRIVER: Wide AC Input 180-264VAC to 24V constant voltage, up to 93% High efficiency

Connecting dimming controllers smoothly.

Built-in active PFC circuit, PF>0.95

NO FLICKER: Please confirm the specific Wattage of the products before use to avoid flicker, THD<15%, Ripple<120mV

SAFETY CERTIFICATION: Class 2,SELV, CE, ROHS, ERP, CB, KC

FULL PROTECTION: Plastic case for dry and damp locations; It has Short Circuit/Over Loading /Over temperature/Over Voltage protections that keep your products and projects safety working

HIGH QUALITY: Suitable LED lighting and moving sign applications, 5 years warranty

Model:APF-150-24

Technical Specs:

1.Output Parameters

Rated Output voltage: 24VDC

Rated Output Current:6.25A

Rated Output Power: 150W Max

Efficiency>92%

Line Regulation:±1%

Load Regulation:±1.5%

Voltage tolerance:±3%

2.  Input Parameters

Rated Input voltage:200-240VAC

Input voltage range:180-264VAC, 47-63hz

Input Current Max: 1.5A

Inrush Current<60A

Power Factor>0.95

THD<15%

3. Protection

Overload

Short Circuit

Over voltage

Over Temperature

4. Environment

Operating Temperature range:-30 to +70℃

Storage Temperature range:-40 to +80 ℃

Humidity: 10～95%

Waterproof Level: IP67

5. Safety Standards

UL8750, IEC/EN61347-1,EN61347-2-13,EN62368, GB19510.1,

GB19510.14, IP67 Approved

Withstand voltage: I/P-O/P:3KV

EMI,EMS

EN55015(CISPR15), GB17743, EN61000-3-2 , Class C, EN61000-4-2,

8KV air ; Level 2, 4KV contact, EN61000-4-3, EN61000-4-4,

EN61000-4-5，4KV/Line-Line 6KV/Line-Earth, EN61000-4-6

6. Others

MTBF>200Khours

Dimension:205(L)*70(W)*45(H)mm

Packing: 1.2Kg; 10pcs/13Kg/0.26CBM

Other Output Options Available:
